Technical Specifications
| Specification | Value |
|---|---|
| Purchase Number | HCPM2 |
| Pulling Force | 20 kN |
| Rope Length | 500 m |
| Rope Diameter | 8 mm |
| Cable Pulling Speed | 50 m/min |
| Driving Unit | Hydraulic |
| Engine | Gasoline (Honda GX270) |
| Engine Power | 10 kW |
| Engine Cooling | Air cooled |
| Chassis | Single axle |
| Brake System | Overrun |
| Enclosure | Standard Brenda enclosure (optional metal enclosure) |
| Color | Standard RAL 1028 or RAL 1034 (optional RAL 3020) |
| Length | 3000 mm |
| Width | 1700 mm |
| Height | 1300 mm |
| Tyres | 2 |
| Empty Weight | 750 kg |
